Cambridge Audio EVO Series – The Evolution of Hi-Fi
Evolution means transformation, improvement and progress. At Cambridge Audio, it means hi-fi ready for today, able to fit into your lifestyle and made to look as good as it sounds. It means taking over 50 years’ worth of audio expertise and fitting it all into a single revolutionary product. We’ve developed Evo so you can enjoy the best of both worlds. You can enjoy our incredible, full-on hi-fi sound, with all its precision, scale and emotional expression. But you can also enjoy this extraordinary sound quality from a
compact, convenient, good-looking all-in-one system.
Industry-Leading Feature
Product Line of the EVO Series
×
| EVO 75 |
| POWER OUTPUT |
75W into 8 Ohms |
| AMPLIFICATION |
Class-D Hypex Ncore® |
| DAC |
ESS Sabre ES9016K2M |
| FREQUENCY RESPONSE |
20Hz – 20kHz +0/-3dB |
| ANALOGUE AUDIO INPUTS |
1 x RCA |
| DIGITAL AUDIO INPUTS |
1 x TOSLINK optical, 1 x S/PDIF coaxial, 1 x TV ARC |
| BLUETOOTH |
4.2 A2DP/AVRCP supporting SBC, aptX and aptX HD codecs |
| COMPATIBILITY |
TOSLINK optical: 16/24bit 32-96kHz PCM only S/PDIF coaxial: 16/24bit 32-192kHz PCM only, Bluetooth: 4.2 A2DP/AVRCP supporting up to aptX HD (24bit 48kHz) UPnP, Local USB media, Airplay 2, Chromecast built-in, Internet Radio, Spotify Connect, TIDAL, MQA, Qobuz, Roon Ready. |
| AUDIO FORMATS |
ALAC, WAV, FLAC, AIFF, DSD (x256), WMA, MP3, AAC, HE AAC AAC+, OGG Vorbis |
| OUTPUTS |
Speakers, 3.5mm headphone, Preamp Output, Subwoofer Output, Bluetooth: 4.2 A2DP/AVRCP supporting up to aptX HD |
| ETHERNET |
IEEE 802.3, 10 Base-T or 100 Base-T |
| WI-FI |
Dual Band 2.4/5gHz |
| MAX POWER CONSUMPTION |
400w |
| STANDBY POWER CONSUMPTION |
<0.5w |
| DIMENSIONS (W X H X D) |
317 x 89 x 352mm |
| WEIGHT |
5.0 kg |
| WHAT'S IN THE BOX |
Evo 75 All-in-One Player, Quick Start Guide, Safety Guide, Remote Control, Mains Lead, 2 x AAA Batteries, Customisable Side Panels x 2 |
×
| EVO 150 |
| POWER OUTPUT |
150W into 8 Ohms |
| AMPLIFICATION |
Class-D Hypex Ncore® |
| DAC |
ESS Sabre ES9018K2M |
| FREQUENCY RESPONSE |
20Hz – 20kHz +0/-3dB |
| ANALOGUE AUDIO INPUTS |
1 x RCA, 1 x balanced XLR, 1 x Moving Magnet Phonostage |
| DIGITAL AUDIO INPUTS |
2 x TOSLINK optical, 1 x S/PDIF coaxial, 1 x TV ARC |
| USB AUDIO INPUT |
USB Type B conforming to USB Audio Class 1 or USB Audio Class 2 (user selectable) |
| BLUETOOTH |
4.2 A2DP/AVRCP supporting SBC, aptX and aptX HD codecs |
| COMPATIBILITY |
TOSLINK optical: 16/24bit 32-96kHz PCM only S/PDIF coaxial: 16/24bit 32-192kHz PCM only USB Audio Class 1: Up to 24-bit 96kHz (asynchronous) USB Audio Class 2: Up to 24-bit 384kHz (asynchronous) and up to DSD 256 Bluetooth: 4.2 A2DP/AVRCP supporting up to aptX HD (24bit 48kHz) UPnP, Local USB media, Airplay 2, Chromecast built-in, Internet Radio, Spotify Connect, TIDAL, MQA, Qobuz, Roon Ready. |
| AUDIO FORMATS |
ALAC, WAV, FLAC, AIFF, DSD (x256), WMA, MP3, AAC, HE AAC AAC+, OGG Vorbis |
| OUTPUTS |
Speakers A+B, 3.5mm headphone, Preamp Output, Subwoofer Output, Bluetooth: 4.2 A2DP/AVRCP supporting up to aptX HD |
| ETHERNET |
IEEE 802.3, 10 Base-T or 100 Base-T |
| WI-FI |
Dual Band 2.4/5gHz |
| MAX POWER CONSUMPTION |
700w |
| STANDBY POWER CONSUMPTION |
<0.5w |
| DIMENSIONS (W X H X D) |
317 x 89 x 352mm |
| WEIGHT |
5.3 kg |
| WHAT'S IN THE BOX |
Evo 150 All-in-One player, Quick Start Guide, Safety Guide, Mains Lead, Remote Control, 2 x AAA Batteries, Customisable Side Panels x 2 |
×
| EVO S |
| SENSITIVITY |
88dB |
| FREQUENCY RESPONSE |
50Hz - 40 kHz |
| IMPEDANCE |
8 Ohms |
| RECOMMENDED AMPLIFIER POWER |
25-200 watts |
| DRIVERS |
Tweeter: 1 x 25mm (1") silk dome tweeter Mid/Bass: 1 x 165mm (6.5") anodized aluminum cone |
| CROSSOVER |
2 way |
| PORTED |
1 rear ported |
| COLOUR |
Black |
| DIMENSIONS (W X H X D) |
200 x 284 x 216mm |
| WEIGHT |
7.1 kg |
| WHAT'S IN THE BOX |
Evo S Speaker x 2, Magnetic Speaker Grille x 2, Bass Plug x 2, 3m Speaker Cable x 2 (terminated), Quick Start Guide |
Find Out More About The Best Cambridge Audio Products!
What The Press Say
- Anyone unboxing their Evo 150 may not be in a hurry to avert their eyes from the box’s colourful display and eye-grabbing side panels, but they’ll soon notice that the rear panel is absolutely jam-packed with sockets – not bad considering network streaming is the prime focus of this kind of product. While systems such as these often offer a few inputs to serve physical formats, Cambridge has gone the extra mile to be as inclusive as possible.
